发动机 | 型号和型式 Mode&Type | 潍柴WP10G200E355/WD10G200E25 直列,水冷 Weichai,in-line,water-cooled | |||
额定功率 Rated power(kw) | 132.4 kw | ||||
传动系统 | 主离合器型式Main clutch type | 湿式,多片,惯性制动,手动操作,液压助力 Wet,multi-disc,inertia brake,hand operate,hydraulic booster | |||
变速箱Transmission | 强制润滑,手动操作 Forced lubrication, hand operate | ||||
中央传动Main drive | 螺旋锥齿轮,一级减速,飞溅润滑 Spiral bevel gear, single-stage speed reduction,splash lubrication | ||||
转向离合器Steering clutch | 湿式多片,碟簧压紧常接合,手动液压分离与转向制动器联动 | ||||
转向制动器Steering brake | 湿式、浮动带式结构,脚踏制动液压助力 Wet,floating band structure, foot brake with hydraulic booster | ||||
终传动Final drive | 直齿二级减速,飞溅润滑式 Two-stage reduction of spur gear,splash lubrication | ||||
行驶速度 | 档位Gear | 1st | 2nd | 3rd | 4th |
前进Forward(km/h) | 0-2.67km/h | 0-3.76km/h | 0-5.41km/h | 0-7.62km/h | |
后退Reverse(km/h) | 0-3.48km/h | 0-4.90km/h | 0-7.05km/h | 0-9.92km/h | |
行走系统 | 型式Type | 平衡梁、八字梁、半刚性结构 Sprayed beam suspended structure of equalizer | |||
托带轮数Carrier rollers | 3每侧 3 Each side | ||||
支重轮数Track rollers | 9 每侧 9 Each side | ||||
履带型式Track type | 装配式三角齿 Assembled,triangle | ||||
履带板宽度 Width of track shoes | 1200mm | ||||
链轨节距Pitch | 203.2mm | ||||
液压系统 | 高工作油压Max.pressure | 14MPa | |||
油泵型式Pump type | 齿轮油泵 Gear pump | ||||
流量Discharge | 227L/min | ||||
工作油缸内径×数量Working cylinder×number | 110mm×2 | ||||
铲dao Blade | 铲dao类型Blade type | 直倾铲Straight-tilt | |||
铲斗容积Dozing capacity | 4.15m³ | ||||
铲dao宽度Blade width | 4410mm | ||||
铲dao高度Blade height | 972mm | ||||
大铲土深度Max.drop below ground | 510mm | ||||
铲dao大倾斜Max.tilt adjustment | 715mm | ||||
整机外型尺寸长*宽*高 Overall dimension( LxWxH) | 5925×4410×3055mm |
