规格参数 Main Specifications | ||
整机工作重量 | Operating Weight | 18300 kg |
整机尺寸 （长×宽×高） | Overall Dimenssions | 5256×4153×3130 mm |
铲dao类型 | Blade type | 直倾铲 Straight-tilt |
铲dao容量 | Dozing capacity | 3.85 m3 |
铲dao宽度 | Blade width | 4150 mm |
铲dao高度 | Blade height | 960 mm |
大切削深度 | Blade max.drop below ground | 488 mm |
铲dao大倾斜 | Blade max.tilt adjustment | 730mm |
爬坡性能 | Grade ability | 30° |
发动机 Engine | ||
发动机型号 | Model | Weichai WP10G178E355 |
额定功率 | Rated Power | 131/1850 Kw/rpm |
缸数-缸径×行程 | Cylinder number-bore×stroke | 6-126×130mm |
排量 | Piston displacement | 9.726L |
小耗油量 | Mini fule consumption | 214g/kw.h |
大扭矩 | Max torque | 830/1000-1200 N.m/rpm |
冷却方式 | Cooling Type | 水冷 Water |
传动系统 Power transmitting system | ||
主离合器型式 | Main clutch type | 湿式，多片，惯性制动，手动操作，液压助力 wet,multi-disc,inertia,brake,hand operate,hydraulic booster |
变速箱 | Transmission | 强制润滑，手动操作 Forced lubrication, hand operate |
中央传动 | Main drive | 螺旋锥齿轮，一级减速，飞溅润滑 Spiral bevel gear, single stage speed reduction,splash lubrication |
转向离合器 | Steering clutch | 湿式多片，碟簧压紧常接合，手动液压分离与转向制动器联动 Wet multi-disc,spring loaded, hand hydraulically seperated, inter-linking with steering brake |
转向制动器 | Steering brake | 湿式带式结构，脚踏制动液压助力 Wet banding structure, footbrake, hydraulic booster |
终传动 | Final drive | 直齿二级减速，飞溅润滑式 Two-stage reduction of spur gear,splash lubrication |
行走系统 Undercarriage system | ||
托带轮数 | Number of carrier rollers | 4 |
支重轮数 | Number of track rollers | 14 |
履带板宽度 | Width of track shoes | 1100mm |
小离地间隙 | Min.ground clearance | 492 mm |
接地比压 | Ground pressure | 0.026 Mpa |
履带中心距 | Track gauge | 2300 mm |
链轨节数量 | Number of track shoes | 44 |
链轨节距 | Pitch | 203.2mm |
前进 | Forward(km/h) | 2.67/3.76/5.41/7.62/11.13 km/h |
后退 | Reverse(km/h) | 3.48/4.9/7.05/9.92 km/h |
液压系统 Hydraulic system | ||
高工作油压 | Max.pressure | 14MPa |
油泵型式 | Pump type | 齿轮油泵 gear pump |
流量 | Discharge | 227L/min |
工作油缸内径×数量 | Working cylinder×number | 110mm×2 |
